| 产品型号Bearing No | 内径d(mm) | 外径D(mm) | 高度H(mm) | 重量Weight(kgs) |
| 51100 | 10 | 24 | 9 | 0.02 |
| 51101 | 12 | 26 | 9 | 0.022 |
| 51102 | 15 | 28 | 9 | 0.024 |
| 51103 | 17 | 30 | 9 | 0.028 |
| 51104 | 20 | 35 | 10 | 0.04 |
| 51105 | 25 | 42 | 11 | 0.059 |
| 51106 | 30 | 47 | 11 | 0.068 |
| 51107 | 35 | 52 | 12 | 0.09 |
| 51108 | 40 | 60 | 13 | 0.12 |
| 51109 | 45 | 65 | 14 | 0.15 |
| 51110 | 50 | 70 | 14 | 0.16 |
| 51111 | 55 | 78 | 16 | 0.24 |
| 51112 | 60 | 85 | 17 | 0.29 |
| 51113 | 65 | 90 | 18 | 0.34 |
| 51114 | 70 | 95 | 18 | 0.36 |
| 51115 | 75 | 100 | 19 | 0.42 |
| 51116 | 80 | 105 | 19 | 0.43 |
| 51117 | 85 | 110 | 19 | 0.46 |
| 51118 | 90 | 120 | 22 | 0.68 |
| 51120 | 100 | 135 | 25 | 1 |
| 51122 | 110 | 145 | 25 | 1.08 |
| 51124 | 120 | 155 | 25 | 1.2 |
| 51126 | 130 | 170 | 30 | 1.8 |
| 51128 | 140 | 180 | 31 | 2.1 |
| 51130 | 150 | 190 | 31 | 2.2 |
| 51132 | 160 | 200 | 31 | 2.3 |
| 51200 | 10 | 26 | 11 | 0.0293 |
| 51201 | 12 | 28 | 11 | 0.0324 |
| 51202 | 15 | 32 | 12 | 0.0444 |
| 51203 | 17 | 35 | 12 | 0.0506 |
| 51204 | 20 | 40 | 14 | 0.0733 |
| 51205 | 25 | 47 | 15 | 0.109 |
| 51206 | 30 | 52 | 16 | 0.138 |
| 51207 | 35 | 62 | 18 | 0.22 |
| 51208 | 40 | 68 | 19 | 0.27 |
| 51209 | 45 | 73 | 20 | 0.32 |
| 51210 | 50 | 78 | 22 | 0.39 |
| 51211 | 55 | 90 | 25 | 0.619 |
| 51212 | 60 | 95 | 26 | 0.69 |
| 51213 | 65 | 100 | 27 | 0.75 |
| 51214 | 70 | 105 | 27 | 0.79 |
| 51215 | 75 | 110 | 27 | 0.815 |
| 51216 | 80 | 115 | 28 | 0.925 |
| 51217 | 85 | 125 | 31 | 1.3 |
| 51218 | 90 | 135 | 35 | 1.77 |
| 51220 | 100 | 150 | 38 | 2.4 |
| 51222 | 110 | 160 | 38 | 2.6 |
| 51224 | 120 | 170 | 39 | 2.9 |
| 51226 | 130 | 190 | 45 | 4.32 |
| 51228 | 140 | 200 | 46 | 4.6 |
| 51230 | 150 | 215 | 50 | 6.1 |
| 51232 | 160 | 225 | 51 | 6.7 |
| 51304 | 20 | 47 | 18 | 0.15 |
| 51305 | 25 | 52 | 18 | 0.171 |
| 51306 | 30 | 60 | 21 | 0.265 |
| 51307 | 35 | 68 | 24 | 0.378 |
| 51308 | 40 | 78 | 26 | 0.55 |
| 51309 | 45 | 85 | 28 | 0.69 |
| 51310 | 50 | 95 | 31 | 1 |
| 51311 | 55 | 105 | 35 | 1.34 |
| 51312 | 60 | 110 | 35 | 0.43 |
| 51313 | 65 | 115 | 36 | 1.57 |
| 51314 | 70 | 125 | 40 | 1.95 |
| 51315 | 75 | 135 | 44 | 2.7 |
| 51316 | 80 | 140 | 44 | 2.8 |
| 51317 | 85 | 150 | 49 | 3.7 |
| 51318 | 90 | 155 | 50 | 3.9 |
| 51320 | 100 | 170 | 55 | 5.1 |
| 51322 | 110 | 190 | 63 | 7.9 |
| 51405 | 25 | 60 | 24 | 0.34 |
| 51406 | 30 | 70 | 28 | 0.36 |
| 51407 | 35 | 80 | 32 | 0.82 |
| 51408 | 40 | 90 | 36 | 1.18 |
| 51409 | 45 | 100 | 39 | 1.64 |
| 51410 | 50 | 110 | 43 | 1.99 |
| 51411 | 55 | 120 | 48 | 2.64 |
| 51412 | 60 | 130 | 51 | 3.51 |
